High Precision CNC Machine Manufacturing

Free Quote
(940) 566-3306

Our CNC Equipment

Precision CNC machines that deliver high quality parts over and over again completing your order on time and under budget.
Our CNC Equipment

Our CNC Machines are high precision for making quality parts every time.

Halsey Manufacturing employs a wide range of equipment to complete most any CNC Machining project all in house. All of our CNC Milling machines have a 4th axis turret for complex tooling and utilizing advanced machining techniques. All of our milling machines are high end late model HAAS made VMC's Vertical Machining Centers, which are the most versatile CNC Machines available on the market today. One of our HAAS CNC mills is a super speed model that is capable of extremely high speeds up to 12,000 rpm. This is needed for machining with very small tools that require fast RPM's to match the tools small diameter and create enough surface speed for cutting.



We also provide a wide range of CNC Turning equipment including multi-axis lathes otherwise referred to as Swiss-Type Machining. Live tooling on bar stock opens up the CNC capabilities to near limitless abilities greatly enhancing accuracy and reliability. While reducing cost when paired with bar feeders for greater mass manufacturing output to a diameter of 1 3/8" capacity.



Not sure if we have the capability to complete your project?

Call Us at:  (940) 566-3306



Auxilliary Equipment

•Haas VF-3

•Haas VF-0

•Ultima manual mill with D.R.O.

•Jet 1440 engine lathe

•H90-A Hemsaw

•Mig & Tig welding processes





Haas VF-4 SS VMC 30 HP

X - 50"

Y - 20"

Z - 25"

12,000 RPM

30 HP

High Speed 24 station Side mount tool changer



•Haas 4th Axis HRT-210 Rotary Table (360,000 postions)

•Rigid Tapping

•Renishaw Probe

•Haas Tool Setting Probe

Haas VF-4  VMC 20 HP

X - 50"

Y - 20"

Z - 25"

12,000 RPM

20 HP

High Speed 24 station Side mount tool changer



•Haas 4th Axis HRT-210 Rotary Table (360,000 postions)

•Rigid Tapping

Haas HRT-210 Rotary Tables

8" Chuck - 3 Unit Styles

360,000 positions

Direct command 4th axis interface

Renishaw Probe

High Speed tool setting

Precision Part Location

Part Inspection Calibration

Haas Tool Setting probe

High speed tool setting

Precsion Accuracy

Haas Automation

Haas HRT-210 Rotary Tables

8" Chuck - 3 Unit Styles

360,000 positions

Direct command 4th axis interface

Ganesh CYCLONE 4-Axis Turn-Mill Center

•Complete Turning & Milling on One Machine

•18" Full "Y" Axis

•High Performance C Axis - 360,000 Positions

•10 HP / 6,000 RPM Spindle

•18 Total Tools with 7 Live Tools

•1 3/8" Bar Capacity

•Double-Anchored Ball Screws

Hitachi Seiki HITECH-TURN 23J

Chuck Dia. 10"

Bar Capacity 2.75"

Max turning length 24"





Hwacheon HI-ECO 21HS

Chuck Dia. 8"

Bar Capacity 2"

Max turning length 15"





HAAS SL25 Lathe

Chuck Dia. 10"

Bar Capacity 3"

Max turning length 21"





Hitachi Seiki CNC Lathe Turning Machines in our CNC Machine Shop in Dallas Fort Worth Texas TX
CNC Lathe Turning Machines in our CNC Machine Shop lathe manufacturing Dallas Fort Worth Texas TX

Trotec Speedy 300 flexx Laser Engraver

•CO2 Laser; 60 watt

•YAG Fiber Laser; 30 watt

•8.000" Max work height

•29.000" x 17.000" Max work area

•Cuts acrylic up to 0.500"

•Engrave almost any material with dual laser technology!

•Fast cycle time means quick turn-around!
